PedalAsia Geometry	46 (26")	49 (26")
Seat Tube (C-T)	460	490
Seat Tube (C-C)	420	450
Effective Top Tube	550	570
Chain Stay	430	430
Head Tube	120	140
Head Tube Angle	70.5	70.5
Seat Tube Angle	73	73
BB Drop	50	50
Standover	719	746
Top Tube Angle	8.6	7.8
Reach	388	402
Stack	524	542
Fork Rake	45	45
Fork Steering Tube	320	320
Fork Axle to Crown	390	390
Wheelbase	1030	1051
weight（fork）kg	1.26	1.26
weight（Frameset）kg	2.48	2.56

车架型号	Model	Blacksnow Pedal Asia MK1
车架材质	Frame Material	4130 Cr-Mo , main triangle double buttered to 0.9-0.6-0.9mm
前叉材质	Fork Material	4130 Cr-Mo
最大轮胎（不含挡泥板）	Max Tire (w/o fender)	26"2.2
最大轮胎（含挡泥板）	Max Tire (w/ fender)	26" 2.0
前叉高度	Fork Height (axle to crown)	390mm
前叉偏移量	Fork Offset	45mm
头管	Headset	34mm
座管	Seat Post	27.2mm
座管夹	Seat Collar	29.8mm
前变速安装方式	Front Derailleur	28.6mm band-on, down tube pull
五通	Bottom Bracket	68mm BSA threaded
牙盘	Crank set	48-36-26T (max)
前刹车	Front Brake	IS Disc Brake, 160mm Rotor(max)
前轴	Front Axle	10-100mm QR
后刹车	Rear Brake	IS Disc Brake, 160mm Rotor(max)
后轴	Rear Axle	10-135mm QR
后变速挂耳	Rear Derailleur Hanger	Integrated
货架孔	Rack Mounts	Front rack M5 boss, Rear rack M6 boss
挡泥板孔	Fenders	Yes
水壶架数量	Water Bottle Mounts	3 standard
把立尺寸	Stem Clamp	28.6mm
其他	Other features
